Transmission protocol
ipcolor
Latency
Zero latency
Transmission type
Uncompressed transmission
HDMI signal
HDMI 2.0, HDCP 2.2
HDR
HDR10
Optical module type
SFP+
Fiber-optic cable type
Single mode fiber (Use with the default optical modules)
Optical fiber connector type
LC
SFP+ optical fiber module wavelength
1270nm/1330nm
Connection type
One-to-one connection
One-to-many connection
Switch cascading
Transmission distance
≤40km
HDMI Resolution
720P@50/60Hz, 1080P@24/25/50/60 Hz, 1080i@50/60Hz, 1024*768@60Hz, 1280*768@60Hz, 1280*800@60Hz, 1280*960@60Hz, 1280*1024@60Hz, 1440*900@60Hz, 1400*1050@60Hz, 1600*900@60Hz, 1600*1200@60Hz, 1680*1050@60Hz, 1920*1080@60Hz, 1920*1200@60Hz, 2560*1440@60Hz, 2560*1600@60Hz, 3840*2160@24/25/30/50/60/23.9/29.9/59.9Hz, 4096*2160@24/25/30/50/60/23.9/29.9/59.9Hz
Audio formats
LPCM 7.1/DTS-HD/DTS-Audio/Dolby Digital plus /Dolby TrueHD/Dolby Digital/Dolby Atmos
IR
Support bi-directional IR passback (20-60kHz)
RS-232
3 pin: GND-TxD-RxD, follows RS-232 levels
Working temperature
-20~60℃
Storage temperature
-30~70℃
Humidity (no condensation)
0~90% RH
Protection
ESD protection
1a Contact discharge level 3
1b Air discharge level 3
Implementation of the standard: IEC61000-4-2
Lightning protection
Surge protection
Power supply
DC 5V/2A
Power consumption
<7W
Material
Aluminum alloy material + crystal panel
Color
Black
Weight
TX: 420g，RX: 420g
Dimension
123.95(L)*115.20(W)*30.00(H)mm
