Voltage/Current
DC 5V/2A
Power consumption
TX ≤ 7W, RX ≤ 4W
HDMI version
HDMI 2.0
HDCP version
HDCP 1.4/HDCP 2.2
Maximum transfer rate
18Gbps
Resolution supported
4096x2160@30Hz, 3840x2160@24/30/ 50/60Hz, 1080P@50/60Hz, 720P@50/60Hz, 1920x1200, 2560x1440, 2560x1600
Input and output TMDS signal
0.7~1.2Vp-p（TMDS）
Input and output DDC signal
5Vp-p（TTL）
Wi-Fi Frequency bands
5.18~5.24 GHz
Transmission distance
≤ 50m
Latency
80~140ms
Connection types
One-to-one
SSID pairing
Supported
ESD protection
1a Contact discharge level 3
1b Air discharge level 3
Standard: IEC61000-4-2
Infrared frequency
20~60kHz
Receiving range
≤ 5m
Working temperature
-20~60℃
Storage temperature
-30~70℃
Humidity (no condensation)
0~90% RH
Dimension
TX: 115(W) x 125(L) x 20.6(H) mm
RX: 115(W) x 125(L) x 20.6(H) mm
Color
Black
Material
Iron
Net weight
TX: 346g; RX: 338g
