HDMI cable
≤5m
Maximum transfer rate
18Gbps
Maximum transmission bandwidth
600MHz
EDID passthrough
Support
Compatibility
HDMI 2.0（Deep color, 4K, HDR, YUV4:4:4）
HDCP 2.2，HDCP1.4
Resolutions
480i@60Hz、480p@60Hz、576i@50Hz、576p@50Hz、 720p@50/60Hz、1080i@50/60Hz、1080p@50/60Hz、 3840x2160@24/25/30/50/60Hz、4096x2160@24/25Hz、 1280x960、1280x800、1280x768、1680x1050、 1360x768、1366x768、1600x900、1024x768、800x600、 1920x1200
Transmission distance
CAT6/6A/7≤70m
Audio formats
LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby Atmos
Receiving range
≤5m
Infrared frequency
20KHz~60KHz
Power Supply
TX：AC110~240V，RX：PoC (Powerd by TX)
Power Consumption
Tx + Rx < 7W
Working temperature
0℃~60℃
Storage temperature
-30℃~70℃
Humidity
0~90%RH（No condensation）
Housing
Aluminum alloy + Iron
Weight
TX：270g，RX：250g
Color
Silver
Dimensions
TX：70.0(L)*114.0(W)*51.0(H) mm
RX：70.0(L)*114.0(W)*51.0(H) mm
Protection
ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV) Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
