Voltage/Current
DC5V/2A
Power consumption
TX+RX<8W
HDMI compliance
HDMI 1.4
HDCP compliance
HDCP 1.4
HDMI resolution
800x600、1024x768、1280x720、 1280x960、1366x768、1440x900、 1680x1050、1920x1080、480i@60Hz、 480p@60Hz、576i@50Hz、 576p@50Hz、720p@50/60Hz、 1080i@50/60Hz、 1080p@24/25/30/50/60Hz、 3840x2160@24/25/30Hz
Audio formats
DTS、DTS-HD、PCM、LPCM
HDR
Support
EDID through
Support
IR Pass-back
Frequency Range：20~60KHz
Input and output TMDS signal
0.7~1.2Vp-p(TMDS)
Input and output DDC signal
5Vp-p(TTL)
Cat6/6A/7
1080p@60Hz transmission 70 meters
4K@30Hz transmission 40 meters
Electrostatic protection of the whole machine
Implementation of the standard:
IEC61000-4-2
1a Contact discharge level 2（±4KV）
1b Air discharge level 3 (±8KV)
Working temperature
-20~60℃
Storage temperature
-30~70℃
Humidity (no condensation)
0～90%RH
Dimension
75.0(L) x 60.0(W) x 16.5(H) mm
Weight
TX:127g RX:127g
Color
Black
