HDMI Signal
HDMI 1.3, fully compatibale HDCP1.2
HDMI DDC Signal
5Vp-p（TTL）
HDMI TMDS Signal
0.5~1.5Vp-p（TMDS）
Input HDMI Resolution Supported
480i@60Hz，480p@60Hz，576i@50Hz，576p@50Hz，720p@50/60Hz，1080p@24/25/30/50/60Hz
Video Encoding
H.264
Audio Encoding
MPEG2
Coaxial output Standard
DVB-T
Coaxial Cable reqired
RG6，RG7，RG11
Frequency
177.5 to 866MHz
Effective Bitrate
Max：24M bits
Insert Loss
0dBm
RF output Wattage(TX)
-40dBm~13dBm
RF Interface
British system（75Ω type F）
Delay Time
200~300ms（Depends on the decoding ability of receivers）
Audio format
Stereo PMC（44.1kbps, 48kbps）
Power Supply
DC12V/1A
Product Consumption
<7W
Working temperature
~20~60℃
Stock temperature
~30~70℃
Relative Humidity
0~90%RH（No Condensation）
Product Dimension
158x114.3x33mm
Weight
520g
Color
Black
